SIEMENS SINAMICS V20

The versatile inverter for basic solutions


The SINAMICS V20 sets itself apart as a result of its quick commissioning times, ease of operation, robustness and cost-efficiency. With seven frame sizes, it covers a power range extending from 0.12 kW up to 30 kW.

With the frame sizes FSAA and FSAB for the single-phase 230V mains operation, the SINAMICS V20 is Siemens smallest inverter on the market so far. With a width of just 68 millimeters and a height of 142 millimeters, Siemens have substantially reduced the installation dimensions of the SINAMICS V20 for low powered motors.


Functions

  • Commissioning with commissioning wizard
  • Parameter setting and saving
  • Run motor in JOG mode
  • Monitoring converter status
  • Quick diagnosis
  • Backup and restore settings


Easy to install

  • Push-through and wall mounting – side-by-side possible for both
  • USS and MODBUS RTU at terminals
  • Integrated braking chopper from 7.5 kW to 30 kW (10 hp up to 40 hp)
  • Electromagnetic compatibility (EMC) category C1/C2


Easy to use

  • Parameter loading without power supply
  • Easy commissioning, operation and diagnosis with the webserver module SINAMICS V20 Smart Access
  • Integrated application and connection macros
  • Keep Running Mode for uninterrupted operation
  • Wide voltage range, advanced cooling design and coated PCBs increase robustness

Overview


Voltage and power range:1AC 200 V - 240 V,  ±10 %

3AC 380 V - 480 V +10 % / -15 %

0.12 kW - 30 kW (0.17 hp up to 40 hp)
Control Modes:V/f, V2/f, FCC, V/f multi-point
