Overview

Series       Tooth     Description & Material
Module
Available
Tooth
Treatment
Quality
06 straight soft
stainless
X8 CrNiS 18 9
1; 1,5; 2; 3 none 8
07 straight soft
Ck45
5 & 10 mm
pitch
none 8
20 straight
&
helical
pinion shaft for
key connection
case hardening steel
1,5; 2; 3; 4; 5; 6 case-hardened 6
21 straight soft
C45
1; 1,5; 2; 2,5; 3;
4; 5; 6; 8; 10; 12
none 8
21 helical soft
C45
1,5; 2; 3; 4; 5;
6; 8; 10; 12
none 8
22 straight plastic 1; 1,5; 2; 2,5; 3 none 9
23 straight cast iron 1; 1,5; 2; 2,5; 3;
4; 5; 6
non 8
24 straight hardened & ground
16MnCr5
2; 3; 4; 5; 6 case-hardened & ground 6
24.98 straight hardened & ground
for rework
16MnCr5
2; 3; 4; 5; 6 carburized,
teeth induction hardened
6
24 helical hardened & ground
16MnCr5
1,5; 2; 3; 4; 5; 6;
8; 10
case-hardened & ground 6
24.99 helical hardened & ground
for rework
16MnCr5
2;
3; 4; 5; 6; 8
carburized,
teeth induction hardened
6
24.0
24.7
straight hardened & ground
16MnCr5
5; 10 & 13,33 mm
Teilung
case-hardened & ground 7
74 helical pre-load pinion shaft
case hardening steel
2; 3; 4; 5; 6; 8 case-hardened & ground 7
78 helical hardened & ground
for EN ISO 9409-1-A interface
16MnCr5
2; 3; 4; 5 case-hardened & ground 5
78 helical TR-pinion
hardened & ground
wirth flange for EN ISO 9409-1-A interface
16MnCr5
2; 3; 4; 5; 6; 8 case-hardened & ground 5
78 straight TR-pinion
hardened & ground
wirth flange for EN ISO 9409-1-A interface
16MnCr5
2; 3; 4; 5; 6; 8 case-hardened & ground 5
79 helical hardened & ground with
spline profile acc. DIN 5480
1,5; 2; 3; 4 case-hardened & ground 5
